Borosilicate Glass Tube Size

borosilicate glass tubes play a crucial role in various industries where thermal resistance, chemical inertness, and transparency are required, making them versatile materials for a wide range of applications.

Out Diameter Wall Thickness Max Length Out Diameter Wall Thickness Max Length Out Diameter Wall Thickness Max Length Out Diameter Wall Thickness Max Length
OD WT 　 OD WT 　 OD WT 　 OD WT 　
mm mm mm mm mm mm mm mm mm mm mm mm
4.8 0.9 1200 19.0 2.5 2200 38.0 3.0 1800 80.0 3.0 2050
5.0 1.0 1700 19.0 2.8 3200 38.0 3.5 1800 80.0 3.0 1750
5.0 1.5 1700 19.0 3.0 1500 40.0 2.0 1800 80.0 5.0 1800
6.0 1.0 1600 20.0 1.2 1800 40.0 2.5 1800 83.0 2.5 1800
6.5 2.5 1200 20.0 1.5 1800 40.0 3.4 2000 85.0 2.5 1800
7.0 1.0 1700 20.0 1.8 1700 42.0 2.0 2000 85.0 4.8 2200
7.0 1.2 1700 20.0 2.0 1800 42.0 2.8 1800 90.0 2.5 2000
7.0 3.2 1700 20.0 3.2 2000 42.0 2.7 1800 90.0 3.0 2000
7.0 2.7 1700 22.0 1.2 1800 45.0 2.0 1800 90.0 5.0 2000
7.8 2.5 1700 22.0 1.5 1700 45.0 2.5 1800 95.0 2.4 1800
8.0 1.2 1700 22.0 1.8 1800 45.0 3.5 2200 98.0 2.7 1700
8.0 1.5 1700 22.0 2.2 1700 47.0 2.1 1800 100.0 3.0 2000
8.0 1.5 2000 22.3 3.0 1700 47.0 3.0 1800 100.0 5.0 2000
9.0 1.2 1700 24.7 1.3 1600 50.0 2.0 2000 102.0 2.5 2200
9.0 1.5 1700 25.0 1.5 1700 50.0 2.1 1400 105.0 3.0 1800
9.0 2.0 1700 25.0 2.0 1800 50.0 2.5 2000 105.0 4.8 2200
10.0 1.2 1700 25.0 2.5 2200 50.0 3.5 1800 108.0 3.0 1500
10.0 1.5 1700 25.0 2.5 1800 50.0 5.0 1800 110.0 3.0 2100
10.5 2.0 1700 25.0 3.0 1800 51.0 4.8 1800 112.0 4.8 2200
10.7 1.4 1700 26.0 2.8 2200 55.0 2.5 1400 120.0 3.0 2000
11.0 1.2 1700 27.0 1.8 1700 55.0 2.5 2000 130.0 5.0 1800
11.0 1.5 2100 27.0 2.5 1800 55.0 3.5 2000 132.0 3.8 2200
11.5 1.5 1500 28.0 1.5 1800 58.0 4.0 2200 135.0 5.0 1800
12.0 1.2 1700 28.0 2.0 1800 60.0 2.5 1800 140.0 4.5 2000
12.0 1.5 1700 28.0 2.5 1800 60.0 3.0 1750 150.0 3.0 2000
12.0 2.0 2200 28.0 2.5 2100 60.0 5.0 1700 150.0 4.0 1800
12.5 2.0 2100 30.0 1.2 1800 65.0 2.5 2000 150.0 5.0 1800
12.7 2.2 1200 30.0 1.5 1800 65.0 3.0 1800 160.0 5.0 1800
13.0 1.2 1700 30.0 2.0 1800 70.0 2.5 2000 180.0 5.0 1800
13.0 1.5 1700 30.0 3.0 1800 70.0 4.7 1700 200.0 5.0 1700
13.0 2.0 2000 30.0 4.0 1800 75.0 2.5 1800 220.0 5.0 1500
14.0 1.2 1700 30.0 5.0 1800 75.0 2.5 2000 230.0 8.0 1600
14.0 1.5 1700 32.0 1.5 1800 80.0 2.5 2000 230.0 7.0 1700
14.0 1.5 2100 32.0 2.0 1800 80.0 3.0 1500 180.0 8.0 1500
14.0 2.0 1700 32.0 2.5 2100
15.0 1.2 1700 32.0 3.0 2100
15.0 1.5 1700 32.0 3.4 2200
15.0 1.9 1700 34.0 2.7 900
15.5 2.5 2200 35.0 1.5 1800
16.0 1.5 1700 35.0 2.0 1700
16.0 1.8 1700 35.0 2.5 1800
17.0 1.8 1700 36.0 2.5 900
17.0 2.0 1800 36.0 2.5 1800
18.0 1.2 1700 36.0 3.0 2100
18.0 1.5 1700 37.0 2.5 900
18.0 1.8 1700 38.0 2.0 1800



60 products
  • OD 80mm,WT 9mm,Glass Tube
    $8.00
    $8.00
    $10.00
    Sold out
  • OD 100mm glass tube for patio gas heater,tubular gauge glass
    $0.00
    $0.00
    $35.00
    Sold out
  • $0.00
    $0.00
    $10.00
    Sold out
  • $0.00
    $0.00
    $10.00
    Sold out
  • Quartz glass tube high temperature resistance for patio heater
    $210.00
    $210.00
    Sold out
  • Level indicator level gauge small tubular sight glass glass tube level gauge
    $85.00
    $85.00
    Sold out
  • Borosilicate glass tube with plastic base for hydrometer
    $0.00
    $0.00
    Sold out
  • Quartz glass tube big outer diameter
    $0.00
    $0.00
    Sold out
  • Quartz glass tube small outer diameter
    $0.00
    $0.00
    Sold out
  • Quartz glass tube
    $0.00
    $0.00
    Sold out
  • Tubular Liquid Level Water Gauge Assemblies 1/2''NPT 1/2''and 5/8'' diameter glass tube
    $0.00
    $0.00
    Sold out
  • Oil sight glass max temperature 200℃ stainless steel body borosilicate glass tube
    $0.00
    $0.00
